D Series Head Codes


  • Please log in to reply
24 replies to this topic

#1 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 10 April 2004 - 07:13 AM

Moved here from ALTHonda -

OK guys, I saw a thread started on H-T by a fellow d series enthusiast and thought that we could probably help out. Here is a copy of his post, add where you can. I think it will be a good addition to our archives here too.

"Please help out and post up the code on your D Series Cylinder Head,its located above the exhaust ports of Cyl #2 and #3 or near that location,see pic below.You have to post/know the Year,Model,Engine and Transmission along with the code.I have a few so far.....The Idea of this page is to help people ID thier head when they buy one from ebay,junkyard or anybody so they know they got the right head.

D14A1 (EDM)
1989 Civic GL HB twin carb 5spd ------PM2/E1

D14A3 (EDM)
1997 1.4i HB 5spd-------------------P2A-9
Euro spec D14A3 pre 1988 head code: P2A-9------1500cc GT 3rd gen

D15B1
1990 Std D15B1 4sp--------------PM9-5
1991 Std D15B1 4sp--------------PM9-3

D15B2
88 ?? Hatch Auto------------------PM3-8
90 LX D15B2 5sp------------------PM3-9 (9/0) stamped rs of code
91 CRX DX D15b2 5sp------------PM8-12
93 Civic Eg4 (EDM) D15B2 5sp---PM3-8 (9/4)



D15B6
89 crx hf 5 spd--------------------pm8-2 located above #4 exh runner

D15B7
94 DX D15B7 5sp-----------------PMS-1
95 DX D15b7 5sp-----------------PM9-5
95 LX Sedan 5sp------------------PM9-2

D15B8
92 Civic CX 5sp-------------------PM8-1
D15B8
92 Civic CX H/B manual transmission-------PM8-

D15B (JDM)
92 VTi D15B Auto---------------- P08-1 (9/1)<-- RS of Code

D15B SOHC VTEC 3 STAGE
96 ?? -----------------P2J (9/5) manifold code P2J

D15Z1
92 VX D15Z1 5sp-----------------P07-1

D16A6
88 RT D16A6 Auto----------------PM3-7
90 Si D16A6 5sp------------------PM3-4
90 civic si 5spd-------------------pm3-1


D16Z6
92 Si D16Z6 5sp----------------- P08-2 (9/2) stamped on RS of code.
93 Si D16Z6 5sp------------------P08-4 (9/3) stamped on rs of head
93 EX D16Z6 5spd--------------- P08-4
93 EX D16Z6 5sp-----------------P08-3
94 EX D16z6 5 spd-------------- PO8-2
94 Si D16z6 5sp----------------- P08-3
94 EX D16Z6 5sp-----------------P08-4
94 SI D16z6 5sp ----------------P08-5
95 EX D16Z6 Auto----------------P08-2

D16Y4
96 GLi D16Y4 5sp-----------------P2A-2 "96" stamped on right

D16Y7
97 LX D16Y7 5sp-----------------P2F-HA-2
97 LX D16Y7 Auto----------------P2F-HA-4 also had USA and (9/6) stamped on it
98 DX D16Y7 5sp----------------P2F-HA-3 also has USA and (9/7) stamped on it
00 DX D16Y7 Auto --------------P2F-HA-7

D16Y8
96 EX D16Y8 Auto------P2J-2 stamped 95 on rs of head
97 EX D16y8 5spd-----P2J-4 --- "97" stamped on the right
97 EX D16Y8 Auto-----P2J-6 "97" stamped on rs of head
97 EX D16Y8 Auto-----P2J-7
97 EX D16Y8 5sp-----P2J-6 "96" stamped on right side
97 EX D16Y8 5pd-----P2J-4 (95 stamped on rs)
98 EX D16Y8 Auto-----P23-2
98 EX D16Y8 Auto-----P2J-5 (98 stamped on rs)
99 EX D16Y8 5sp------P2J-4
99 EX D16Y8 5spd-----P2J-7 (99 stamped on rs)
00 EX D16Y8 5sp------P2J-3 "99" stamped on right side
D15b6
89 crx hf 5 spd-------pm8-2 located above #4 exh runner

JDM

THE OBD-II 3 stage VTEC D15B 96^
(2) VTEC solenoids
Head Code "P2J"
year Code "95"
intake mani also stamped "P2J" on the back

OBD-1 SOHC ZC VTEC b]
Head Code "P08-3"
1996 ^ SOHC ZC NON VTEC
Head Code "P2A-10"
Year Code "98"
several of these with years varying from 96-00
All with head codes from P2A-8, 9 and 10












what it looks like..
Posted Image


This is a good start, but I know we should be able to add to this list. All new information I will post back for him (D-man).

Thanks guys.[b]


#2 Mike (4dr)

Mike (4dr)

    Man with the Plan

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 8,237 posts
  • Gender:Male
  • Location:Southern California
  • Interests:Lots of crap.

Posted 10 April 2004 - 08:55 AM

anothony, see staff table. :cool:

#3 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 10 April 2004 - 09:32 AM

OK, you guys have it under control - I'll waste no more of my time moving posts.

Thanks for the heads up Mike 8) !

#4 Matt (SilverY2K)

Matt (SilverY2K)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 1,399 posts
  • Location:626, So. Cali

Posted 10 April 2004 - 02:35 PM

Just a little more SOHChonda dirty work for this thread, a la picture style... This is the stamp on my '00 DX coupe's D16Y7 head:

Posted Image

#5 Darocrx

Darocrx

    Member

  • Intermediate Member
  • Pip
  • 166 posts
  • Location:Michigan
  • Interests:Workin on cars, and school

Posted 10 April 2004 - 07:00 PM

Thanx for this post civicminded. This helped me a lot cuz i wasnt sure if i had the d16a6 head or the d15b7 head because the first guy i bought the engine from decided to put a d15b7 IM on it and i didnt know if he swaped the head too.
Thanx again
  • 0

#6 lilol89crx

lilol89crx

    Member

  • Members
  • Pip
  • 64 posts
  • Location:NC foo!
  • Interests:drag racing

Posted 10 April 2004 - 08:20 PM

D15b6
89 crx hf 5 spd-------pm8-2 located above #4 exh runner
d16a6
90 civic si 5spd-------pm3-1
  • 0

#7 Matt (SilverY2K)

Matt (SilverY2K)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 1,399 posts
  • Location:626, So. Cali

Posted 11 April 2004 - 03:01 AM

Here's the golden question I'm wondering... What's the differance between the head on my '00 DX coupe (auto tranny) that's in the pic in my post above, and this head: 97 LX D16Y7 Auto------P2F-HA-4 Mine is an HA-7 Is there really no differance, or is there a differance? And why would the head on the SAME motor with the same power and all other spec rating numbers, be different? Is mine "better" perhaps? :-k :?

#8 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 12 April 2004 - 07:18 AM

Thanks for all the replys and information guys - it will be nice resource material.

SilverY2KCivic:

My thought on the question about differences in numbers on heads:
I believe that the major differences in the heads will be denoted by the first part of the code - P2F in this case. I think that the latter add-ons have to do with production place/date/etc rather than head configuration.

#9 Darocrx

Darocrx

    Member

  • Intermediate Member
  • Pip
  • 166 posts
  • Location:Michigan
  • Interests:Workin on cars, and school

Posted 12 April 2004 - 10:59 AM

MAn i have PM3 -3 and 8/8
What head is it?
  • 0

#10 fastrunner

fastrunner

    Member

  • Members
  • Pip
  • 93 posts
  • Gender:Male
  • Location:France

Posted 24 April 2004 - 01:20 PM

Hi
On my Civic Hatchback Lsi engine (= Dx with a D15B2 for EDM) :

D15B2
93 Civic Eg4 (EDM) D15B2 5sp-------PM3-8 (9/4)
  • 0

#11 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 27 April 2004 - 11:25 AM

Keep 'em coming guys - thanks again! =D>

#12 CRYZA SOSAE

CRYZA SOSAE

    Member

  • Members
  • Pip
  • 33 posts
  • Location:SW LONDON

Posted 11 May 2004 - 10:00 AM

PM2 /E1 i bet thats got ya :shock: lololol
  • 0

#13 Goosse

Goosse

    Member

  • Members
  • Pip
  • 62 posts
  • Location:Belgium
  • Interests:cars

Posted 11 May 2004 - 12:27 PM

Euro spec D14A3
head code: P2A-9
  • 0

#14 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 11 May 2004 - 12:48 PM

PM2 /E1     i bet thats got ya  :shock: lololol


....Looks around....I think you do - never seen anything like that. What's the year of car/trim level/market/etc?

#15 CRYZA SOSAE

CRYZA SOSAE

    Member

  • Members
  • Pip
  • 33 posts
  • Location:SW LONDON

Posted 11 May 2004 - 01:41 PM

its the haed code for the EDM honda civic GL H/B d14a1 twin carb , it was a replacement for the 3rd gen 1500cc GT and then was replaced its self by the D15B2 1500 i , it had a very hi spec with elec windows sunroof and mirrors and tac , and a center console ,
  • 0

#16 CRYZA SOSAE

CRYZA SOSAE

    Member

  • Members
  • Pip
  • 33 posts
  • Location:SW LONDON

Posted 18 May 2004 - 09:00 AM

1500cc GT 3rd gen =pre 1988
  • 0

#17 HumanResource

HumanResource

    Member

  • Members
  • Pip
  • 47 posts

Posted 21 May 2004 - 09:34 PM

Here's some info I don't see posted yet
this info is for imported JDM Dseries engines

FOR INQUISITING MINDS OF THE OBD-II 3 stage VTEC D15B 96^
YES I said 3 stage with (2) VTEC solenoids

Head Code "P2J"
year Code "95"
intake mani also stamped "P2J" on the back


[b]OBD-1 SOHC ZC VTEC b]

Head Code "P08-3"


1996 ^ SOHC ZC NON VTEC

Head Code "P2A-10"
Year Code "98"
found several of these with years varying from 96-00
All with head codes from P2A-8, 9 and 10

Yes I got these str8 off the engines they we import
NO this ain't any made up BS
  • 0

#18 Glen

Glen

    Global Relations Manager

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 3,375 posts
  • Location:England
  • Interests:women and cars

Posted 22 May 2004 - 12:48 AM

HumanResource,

first off, welcome to the site.

thanks very much for the info on the JDM headcodes, we really need this information.

Any other info that you are able to source form the JDM engines please share. also note there is a topic regarding engine codes in "global sohc & d-series" we could certainly do with that adding too, if you kanow any info. :grin:

#19 Anthony(civicminded)

Anthony(civicminded)

    SOHCHonda.com Veteran

  • The Senior Staff
  • PipPipPipPipPipPipPipPipPipPip
  • 2,654 posts
  • Gender:Male
  • Location:Northeast Bama
  • Interests:Can I add automobiles here? Ok, cars - particular interest in Honda's with D series engines.

Posted 02 June 2004 - 07:44 AM

Thanks for the info, HumanResource - we are very lacking in the JDM world. Table has been updated to reflect new information.


Keep 'em coming folks - .

#20 RockYourSOHC

RockYourSOHC

    Restricted Newbie!

  • Members
  • 18 posts
  • Interests:Caes, anything with a motor!

Posted 26 July 2004 - 09:53 AM

D15B8
92 Civic CX H/B-------PM8-1
  • 0
